M-Live B.Beat PRO16 Plus 1TB

Features

M-Live B.Beat PRO16 Plus (1TB memory + Wi-FI connection)

B.Beat Pro16 is the perfect device to improve and simplify Live Band performances using Stereo or Multitrack Sequences, also with Video and Images. With B.Beat Pr016 on stage you no longer need Computers, Tablets, Audio/Video Cards, Cables, Mixers. B.Beat Pr016 handles the Sequences and leaves the pleasure of playing, worry-free.

B.BEAT PR016 RECORDS UP TO 12 TRACKS AND INCLUDES A 16 OUT/12 IN SOUND CARD

B.Beat Pro16 manages multi-track audio Backing Tracks and also plays them in sync with videos or images. It has two HDMI outputs for video and prompter for lyrics. It includes a powerful 16 out and 12 in sound card, so you can use your DAW during sound check and optimise backing tracks up to minutes before the show. After the sound check you download everything directly to B.Beat Pr016 and press PLAY!

B.Beat Pro16 reads most audio formats (MP3, Wav, Stems, OGG, AAC, MTA*) and audio projects up to 16 + 8 Mono or 12 Stereo tracks. It reads videos and images in sync with the music. It has a digital mixer with 16 outputs for separate tracks. It has 12 Audio inputs that allow multi-track recording, or you can manage a return from Mixer or other instruments. With 4 potentiometers the musician can independently balance headphone listening, if connected.

The repertoire of Backing Tracks, Playlists and Shows are created with the included App that runs on PC Widows or MacOS. With the same App you can setup Audio outputs, you can get a Click track and much more. Projects can include Music, Video/lmages and MIDI tracks to send information to the many devices on stage.

B.Beat connects via Wi-Fi to Smart devices to read lyrics, music scores and other information during performance. B.Beat reads USB sticks for fast transfer of MP3 Stereo Backing Tracks, with or without Click. 128 Gb internal memory, optional WI Fi connection via M-Pen.

B.Beat Pro16 is also available in a Plus version with 1 Tb internal memory and WI Fi connection included. The
PLUS version allows recording even while playing the HARDWARE & internal Backing Tracks.

* MTA is a Multitrack Audio format available at www.songservice.it/www.song-service.com

MAIN TECHNICAL FEATURES

•  Compatible audio Formats (when importing):
WAV 44.1 kHz, 48 kHz, 96 kHz 16/14 bit
MP3 fixed bit rate [64 - 320] kbps, MP3 VBR
OGG fixed bit rate [64 - 320] kbps, AAC, STEMS
MTA M-Live (Audio Multitrack)

•  Video and Image Formats: MP4, MOV, AVI. JPG, PNG.

•  Internal Digital Audio Processing:
16 channels D/A 24 Bit Sigma/Delta 48 kHz.
12 channels A/D 24 Bit Sigma/Delta 48kHz.

•  Display: 2.4" OLED monochrome, 128x64

•  Output:
16 Audio Outputs Jack 6.35 mm mono, balanced
Range IOdBu, 2.5 Vrms
Range 20dBu, 5 Vrms (balanced)
THD+N typical -94 dB
SNR typical 112 dB

•  Input:
12 Line Jack 6.35 mm mono inputs, unbalanced
Impedance 10 kQ Range 18dBu, 6 Vrms
THD+N typical -93 dB
SNR typical 107 dB

•  Headphone, Footswitch:
Output Stereo Jack 6.35 mm
Typical SNR 105 dB
Range 6dBu, 1.5 Vrm
Start/stop pedal

•  Internal storage: According to version: 128Gb or with 1TB SSD

•  Network and Midi interface:
RJ45 10/100/1000 Mbps Ethernet socket
MIDI OUT DIN 5-pin standard
MIDI IN via USB-MIDI cable (optional)

•  Power supply: 12VDC, 2A

•  USB port:
2x USB 2.0 Type A per Memory Stick,
WiFi USB interface

•  Remote control: With Tablet/Smartphone and free App

EAN 806812165315
