Audiodesign Pro LIVE SM11 DSP Stage Monitor

AudioDesign Pro

Ref LIVESM11DSP
Compact. Powerful. Spot-on
€376.23

€376.22 VAT excl.

Features

Audiodesign Pro LIVE SM11 DSP

Compact Active Stage Monitor with DSP, High Power and 130 dB SPL

The LIVE SM11 DSP by AudiodesignPro is a professional active stage monitor designed to deliver maximum audio performance, advanced digital control and outstanding versatility in any live, studio or installation setup.
With 1200 W peak power, Class D amplification, and an advanced integrated DSP, this monitor provides a powerful, linear and detailed sound with up to 130 dB SPL, making it ideal for musicians, audio technicians and professional rental companies.
Its compact design makes it perfect for stages of any size, DJ booths, recording studios and mobile setups.
The intelligent DSP offers optimized presets to instantly adapt to different audio sources – vocals, instruments, playback or personal monitoring – ensuring a balanced and controlled sound even at high volumes.

Ideal for

  • Live bands & musicians looking for a robust and powerful stage monitor
  • Drums, guitar, keyboards with dedicated presets for personalized mixes
  • Theatres, clubs, DJ sets and live events thanks to its high versatility
  • Professional audio projects requiring in-depth DSP control via USB
  • Fixed installations needing continuous, dependable performance

Technical Specifications

  • Peak power: up to 1200 W with ultra-efficient Class D amplifier
  • Maximum SPL: 130 dB for impactful performance even in demanding environments
  • Woofer: high-efficiency 10" driver for deep, controlled low frequencies
  • High-frequency driver: 44 mm compression driver with 60° × 90° dispersion, rotatable based on stage requirements
  • Monitor angle: 23° tilted cabinet for optimal on-stage monitoring
  • Integrated DSP: five dedicated presets (including one specifically for drums) to quickly adapt frequency response
  • Advanced control: DSP management via dial + backlit LCD display and USB software control
  • Frequency response: linear 50–20000 Hz for accurate, balanced sound at high volume
  • Dimensions (WxDxH): 46 × 46 × 29 cm
  • Weight: 16 kg

EAN:
