Audiodesign Pro PMS Mini Wireless Systems

Features

Audiodesign Pro PMS Mini

System for wireless audio transmission - reception in UHF

The PMS Mini is an ultra-compact UHF wireless audio system for mono/stereo transmission and reception on 16 channels (501.0 - 599.1 MHz), designed to offer maximum versatility in any context: live, studio, broadcast, educational or corporate presentations.

With small size (only 55 x 65 x 18 mm for 54 g) and long-life rechargeable battery, it is ideal for any portable application. 24-bit / 48 kHz digital transmission ensures crystal-clear audio with a latency of less than 11 ms and a signal-to-noise ratio of -98 dB.

The PMS Mini allows you to:

• Connect an unlimited number of receivers to a single transmitter on the same channel
• Operate up to 4 independent systems simultaneously on different channels
• Operate in mono or stereo mode, adapting to the connected source

Compatible with mixers, musical instruments, smartphones, microphones and PCs, comes with built-in charge LED and charges via USB.

Specifications:

• UHF band: 16 channels (501.0 - 599.1 MHz)
• Sample rate: 24 bit / 48 kH
• Latency: < 11 ms
• S/N ratio: -98 dB
• Dynamics: > 105 dB
• Frequency response: 20 Hz - 20 kHz (+1 / -3 dB)
• Operating distance: up to 30 meters
• TX Battery: 780 mAh / 5 VDC
• RX Battery: 500 mAh / 5 VDC
• Autonomy: about 5 hours
• Dimensions: 55 x 65 x 18 mm
• Weight: 54 g
• Charging: via USB cable (red LED = charging, green = charged)
• Optional: PMS Mini RX additional receiver

SKU: PMS Mini

EAN: 8014719039192
